Shielded Twisted Pair Hybrid Cable | 2/3/4/6/8 Core Power + 4P Network Ethernet | Waterproof & Wear-Resistant
Hybrid Shielded Cable engineered by Shanghai Rousheng integrates 4P Ethernet data with 2-8 core power supply into a single industrial-grade solution. Designed for high-interference environments, it features dual-layer shielding and a rugged waterproof jacket for maximum reliability in outdoor and robotic applications.
.Integrated data and power delivery in one compact cable.
.Superior EMI protection with tinned copper braiding.
.Weatherproof and wear-resistant for harsh industrial use.
.High-flexibility design suitable for drag chain systems.
.Customizable core configurations (2/3/4/6/8 pin power).
In modern industrial environments, space efficiency and signal integrity are paramount. Our Shielded Twisted Pair Hybrid Cable combines high-speed 4P Ethernet data transmission with robust power delivery (up to 8 cores) in a single, durable jacket. Engineered by Shanghai Rousheng Cable, these cables eliminate the need for multiple cable runs, reducing installation costs and potential failure points in complex systems.
Why Choose Our Hybrid Ethernet & Power Solutions?
1. Dual-Shielding Technology for Zero Interference
Equipped with aluminum foil and high-density tinned copper braiding, our cables provide superior EMI protection. This ensures that the high-voltage power cores do not interfere with the sensitive Cat5e/Cat6 data signals, maintaining stable 1Gbps transmission even in electrically “noisy” factory floors.
2. Industrial-Grade Weatherproofing & Durability
Unlike standard indoor cables, our hybrid series features a custom-compounded PUR or specialized PVC jacket. It is specifically designed to be waterproof, UV-resistant, and wear-resistant, making it ideal for outdoor PTZ cameras, robotic arms, and harsh maritime environments.
3. Optimized for Dynamic Motion (Drag Chain Compatible)
As a specialist in high-flex cables, Rousheng ensures this hybrid line supports continuous bending cycles. The internal structure uses finely stranded oxygen-free copper and specialized insulation to prevent core breakage during repetitive motion in drag chains.
Technical Specifications
| Feature | Specification Details |
| Network Component | 4 Pairs (8 Cores) Twisted Pair (Cat5e / Cat6 equivalent) |
| Power Component | 2 / 3 / 4 / 6 / 8 Cores (Optional) |
| Conductor Material | 99.99% Oxygen-Free Finely Stranded Copper |
| Shielding Type | SF/UTP (Al Foil + Tinned Copper Braid >85% Coverage) |
| Outer Jacket | High-Strength PUR / Oil-Resistant PVC (Black/Orange/Green) |
| Temperature Range | Fixed: -40°C to +90°C |
| Voltage Rating | Power: 300/500V |
| Min. Bend Radius | 7.5 x Outer Diameter (Dynamic) |
Application Scenarios
-
CCTV & Security: Powering PTZ cameras while transmitting 4K video feeds.
-
Robotics: Combined power and feedback control for articulated robotic arms.
-
Industrial Ethernet: Connecting PLC systems and sensors in confined spaces.
-
Outdoor Infrastructure: Reliable connectivity for wind turbines and smart city sensors.
Frequently Asked Questions (FAQ)
Q: Can this cable be used in continuous motion drag chains?
A: Yes. We offer a specific “High-Flex” version of this hybrid cable designed for millions of bending cycles. Please specify your travel distance and speed requirements when ordering.
Q: Is the jacket resistant to industrial oils and chemicals?
A: Our PUR jacket version offers excellent resistance to mineral oils, coolants, and common industrial chemicals, adhering to EN 50363-10-2 standards.
Q: Can I customize the power core gauge?
A: Absolutely. We support customization from 0.5mm² to 2.5mm² for power cores to suit your specific voltage drop requirements.
About Shanghai Rousheng Cable Co., Ltd.
With over a decade of expertise, Rousheng Cable specializes in the R&D and manufacturing of high-flexibility drag chain cables and specialty industrial wires. Our facility serves over 100 countries, providing European-standard connectivity solutions that pass rigorous stress tests. We don’t just sell cables; we provide the backbone for your automation.
