PVC Shielded Flexible Cable for Automation Systems | Braided Shield | Low Noise Cable Manufacturer
This PVC shielded flexible cable is designed for automation systems where signal cables run near power equipment, helping reduce noise and maintain reliable transmission.
Key Benefits:
✅ Braided shield reduces EMI and signal interference
✅ Stable performance in automation and control systems
✅ Flexible design for easy installation
✅ Multiple core and size options available
Ideal for control panels, sensors, and industrial automation applications. Custom configurations available.
PVC Shielded Flexible Cable for Automation Systems | Braided Shield | Low Noise Cable Manufacturer
Engineered for Low-Noise Signal Transmission in Automation Equipment
In automation systems where control signals run close to motors, drives, or switching power supplies, electrical noise can affect system stability. This braided shield flexible cable is designed to limit interference and maintain consistent signal performance in such environments.
The cable is commonly used where stable communication between sensors, controllers, and actuators is required.
Typical Use Cases
This cable is typically installed in:
-
Automation control panels with dense wiring layouts
-
Equipment connected to servo drives or VFD systems
-
Sensor and encoder signal circuits
-
Production lines with mixed signal and power routing
Performance Features
Braided Shield for Noise Reduction
The tinned copper braid provides effective coverage, helping reduce electromagnetic interference in industrial environments.
Consistent Signal Transmission
Supports stable low-voltage signal flow, even when installed near high-current equipment.
Flexible for Installation
Fine-strand conductors allow easy routing in confined spaces such as control cabinets.
Durable Outer Jacket
PVC sheath resists abrasion, handling stress, and typical industrial exposure.
Construction Details
-
Conductor: Fine-strand copper (Class 5)
-
Insulation: PVC
-
Shield: Tinned copper braid
-
Outer Jacket: PVC
The braided structure offers improved mechanical strength compared to foil-only shielding.
Technical Parameters
-
Voltage rating: 300/500 V
-
Temperature range: -40°C to +80°C
-
Core count: 2–37 cores
-
Cross section: 0.5–10 mm²
-
Standard reference: IEC 60227-5
-
Compliance: CE, RoHS
When to Use Braided Shield Cable
A braided shield is often selected when:
-
Cables are exposed to continuous electrical noise
-
Mechanical durability of the shield is required
-
Installation involves movement or handling during maintenance
Configuration Options
Available with:
-
Different core configurations and conductor sizes
-
Combined shielding (foil + braid)
-
Alternative jacket materials (LSZH / PUR)
-
Custom identification and packaging
Manufacturing & Quality
Produced under ISO 9001:2015 quality control system.
Routine testing includes conductor resistance and insulation verification.
FAQ
Q1: When should I choose a braided shield instead of foil shield?
Braided shielding is preferred when better mechanical strength and durability are required, especially in environments with movement or handling.
Q2: Is this cable suitable for VFD and servo systems?
Yes, it is commonly used near VFDs and servo drives to reduce interference and improve signal stability.
Q3: Can this cable be used for data or control signals?
It is suitable for low-voltage control, signal, and instrumentation circuits.
Q4: Do you offer custom configurations?
Yes, core count, conductor size, shielding type, and jacket materials can be customized.
Technical Support
If your system involves noise-sensitive signals or mixed wiring conditions, provide your installation details.
A suitable cable configuration can be recommended based on actual usage.
